Standard Comporision:
| Standard | GB | JFE | SUMITOMO | DILLODUR | SSAB |
| Grade | NM500 | JFE-EH500 | K500 | 500V | Hardox500 |
Chemical Composition:
| Grade | C | Si | Mn | P | S | Cr | Ni | Mo | Ti | B | Als |
| NM500 | ≤0.38 | ≤0.70 | ≤1.70 | ≤0.020 | ≤0.010 | ≤1.50 | ≤1.00 | ≤0.65 | ≤0.50 | 0.0005-0.006 | ≥0.01 |
Available Size:
| Shape: | Available Status | Available size(mm) |
| Plate | Y | 3-120X1500-2300X2500-5800 |
| Flat bar | N | * |
| Sheet | N | * |
| Block | N | * |
| Round bar | N | * |
| Hexagonal bar | N | * |
Delivery Condition:
Hot rolled/Forged+Black surface/Peeled/Rough turned
Delivery time:
Warehouse regular stock sizes:3-7 days
Mill manufacture sizes:15-60 days
Brief introduction:
NM500 Steel is one steel grade in GB standard GB 24186. NM 500 steel is a high-strength, wear-resistant / abrasion resistant steel known for its superior hardness and durability. This steel is specifically designed to withstand high wear conditions and provide extended service life in challenging environments. With a hardness range of 470-540 HBW, NM500 is widely used in applications where resistance to abrasion is a primary concern, such as in mining equipment, construction machinery, and other heavy-duty applications. The strength of NM500 wear-resistant steel is more than 3 times that of ordinary low-alloy steel plates, and the wear-resistant performance can be increased by 2-3 times, significantly extending the service life of the steel plates.
Application:
-Mining equipment
-Construction machinery
-Heavy-duty trucks
-Industrial machinery
-Wear plates and liners
